Making available clean and safe drinking water is an emerging area of concern, particularly in the rural areas. It has been estimated that a staggering 90 million people of Indian villages do not get access to safe drinking water sources.
SHIVAM’s RURALPAK unit produces safe drinking water from the surface water like pond,river, canal etc. and can produce a drinking water at flow of 25m3/hr which is the typical demand for the community use.

SHIVAM’s RURALPAK is a very compact unit consisting of pump, static mixer, Flocculator, Lamella Clarifier,gravity sand filter and dosing system.It is designed to produce 25 m3/hr drinking water from the raw water having total suspended solids (TSS) as high as 500 mg/l.

Static Mixer:-

The raw water is pumped to static mixer.The static mixture is a stationery device to thoroughly mix the chemicals with the raw water.Coagulant such as alum is dosed prior to static mixer.Sodium Hypochloride is dosed for disinfecting water.

Flocculator:-

The water from static mixer is fed into flocculator.During the retention time in the flocculator, the coagulated particles comes together and forms large flocs that can easily settle in the clarifier.

Lamella Clarifier:-

The large flocs slide down on inclined plates and accumulates in hopper bottom of the clarifier from where sludge is drained out. Clarified water comes out from the top of the clarifier having total suspended solids (TSS) below 20 mg/l.

Filter:-

The clarified water from lamella clarifier comes to the gravity sand filter from top for further removal of suspended solids.The unit also have the facility of backwashing of the sand filter. At a regular intervals (typically 8 hours) the sand filter is backwashed.
